Opis i karakteristike
Features
Input frequency: 50/60 Hz
Output power capacity: 3 kVA
UPS topology: LineInteractive
Output operation voltage (min): 208 V
Hold time (max): 10 ms
Surge protection: Yes
Noise level: 55 dB
Surge energy rating: 645 J
Waveform: Sine
Efficiency: 98.5%
Audible alarm(s): Yes
Hold time (min): 2 ms
Output frequency regulation: 50/60 Hz
Automatic Voltage Regulation (AVR): Yes
Output operation voltage (max): 240 V
Autorestart: Yes
Output power: 2700 W
Emergency Power Off (EPO): Yes
Design
Rack capacity: 2U
Form factor: Rackmount/Tower
LED indicators: Battery replacement
Product colour: Black
Cable length: 2.44 m
Operational conditions
Storage relative humidity (HH): 0 95%
Operating altitude: 0 3000 m
Operating temperature (TT): 0 40 C
Operating relative humidity (HH): 0 95%
Nonoperating altitude: 0 15000 m
Storage temperature (TT): 15 45 C
Weight & dimensions
Weight: 37.3 kg
Height: 85 mm
Depth: 667 mm
Width: 432 mm
Packaging data
Package weight: 45.4 kg
Package width: 596 mm
Temperature sensor: Yes
Package height: 85 mm
Software CD: Yes
Package depth: 869 mm
Packaging content
Cables included: RS232
Management card included: Yes
Manual: Yes
Rack mount kit: Yes
Certification: Ctick, CE, EN 500911, EN 500912, EN 55022 Class A, EN 60950, FCC Part 15 Class A, GOST, IRAM, UL 1778, VDE, REACH, PEP, EOLI
Certificates
Compliance certificates: RoHS
Ports & interfaces
SmartConnect port: No
SmartSlot: Yes
AC outlet types: C19 coupler, C13 coupler
Number of output IEC jumpers: 2
Power plug: C20 coupler
AC outlets quantity: 9 AC outlet(s)
Battery
Battery capacity: 738 VAh
Typical backup time at half load: 18 min
Hotswap battery: Yes
Automatic battery test: Yes
Battery life (max): 5 year(s)
Battery technology: Sealed Lead Acid (VRLA)
Typical backup time at full load: 6.25 min
Battery recharge time: 3 h
Packaging content: Web/SNMP Management Card
Other features
Nominal input voltage: 230 V
Nominal output voltage: 230 V
Logistics data
Total carbon footprint (kg of CO2e): 2723.74
Products per pallet: 8 pc(s)
Harmonized System (HS) code: 85078000
Sustainability
Sustainability certificates: Green Premium
