Prilagodi prikaz proizvoda za usporedbu
Opis i karakteristike
Technical details
Warranty period: 2 year(s)
Sustainability compliance: Yes
Compliance certificates: RoHS, CE, REACH, Federal Communications Commission (FCC), UKCA
Certification: California Proposition 65
Features
Audio formats supported: LPCM
HDCP: Yes
HDCP version: 2.2
Maximum resolution: 3840 x 2160 pixels
Type: AV transmitter & receiver
Material: Metal
Supported video modes: 1080p
Product colour: Black
Bandwidth: 18 Gbit/s
Infrared (IR) frequency range: 20 60 kHz
EDID management: Yes
Maximum transfer distance: 150 m
Cable types supported: Cat6
High Dynamic Range (HDR) supported: Yes
SignaltoNoise Ratio (SNR): 90 dB
HDCP passthrough: Yes
On/off switch: Yes
Power
Power requirements: 60 W
AC input voltage: 100 240 V
Power source type: AC
AC input frequency: 50/60 Hz
Operational conditions
Storage temperature (TT): 20 60 C
Operating temperature (TT): 0 40 C
Operating relative humidity (HH): 20 90%
Weight & dimensions
Depth: 200 mm
Weight: 5.31 kg
Width: 440 mm
Height: 45 mm
Receiver dimensions (WxDxH): 140 x 65 x 18 mm
Packaging data
Package width: 510 mm
Package depth: 401 mm
Package height: 98 mm
Package type: Box
Package weight: 6.33 kg
Packaging content: 4x4 HDBaseT Extender Matrix Transmitter 4 x HDBaseT Receivers 5 x IR Emitter Cable, 1.5m 5 x IR Receiver Cable, 1.5m 10 x Mounting Ears & Screws 4 x 3Pin Terminal Block 4 x 5Pin Terminal Block RS232 Male to Female cable, 1.5m 4 x mains cables (EU, UK, US & AUS), 1.5m Lindy Manual
Packaging content
Manual: Yes
Ports & interfaces
HDMI version: 2.0
RS232 input ports: 2
Connectivity technology: Wired
Digital audio coaxial out: 4
Audio RCA outputs: 4
3.5 mm (1/8inch) out: Yes
RJ45 output ports: 4
HDMI in: 4
HDBaseT port: Yes
3.5 mm (1/8inch) in: Yes
Number of HDMI outputs: 5
Audio (L/R) out: 4
