Opis i karakteristike
Design
Cooling type: Active
Fan diameter: 12 cm
Product colour: Black
Number of fans: 1 fan(s)
Fan speed: 0 1800 RPM
Power
AC input frequency: 50/60 Hz
Power protection features: Overheating, Short circuit, Over voltage, Over power, Under voltage, Over current
Input current: 4 8 A
AC input voltage: 100 240 V
Total power: 550 W
Efficiency: 90%
Combined power (+5V): 120 W
Combined power (12V): 3.6 W
Combined power (+12V): 549.6 W
Max output current (+5Vsb): 3 A
Max output current (+5V): 20 A
Max output current (+3.3V): 20 A
Hold time: 16 ms
Combined power (+5Vsb): 15 W
Max output current (+12V): 45.8 A
Combined power (+3.3V): 120 W
Max output current (12V): 0.3 A
Power Factor Correction (PFC) type: Active
Power Good signal delay range: 100 150 ms
Operational conditions
Operating temperature (TT): 0 40 C
Weight & dimensions
Height: 86 mm
Depth: 140 mm
Weight: 1.57 kg
Width: 150 mm
Performance
Purpose: PC/Server
80 PLUS certification: 80 PLUS Gold
Mean time between failures (MTBF): 100000 h
Power supply unit (PSU) form factor: ATX
Bearing technology: HDB
ATX version: 3.1
Packaging data
Package width: 190 mm
Package weight: 1.98 kg
Package depth: 260 mm
Package height: 110 mm
Certification: ErP 2014 Lot 3
Certificates
Compliance certificates: UKCA, RCM, BIS, RoHS, China Compulsory Certification (CCC), CCC, BSMI, KC, REACH, Federal Communications Commission (FCC), EAC, cTUVus
Ports & interfaces
Peripheral (Molex) power connectors (4pin): 3
EPS power connector (8pin): Yes
PCI Express power connectors (6+2 pin): 2
Motherboard power cable length: 50 cm
SATA power cable length: 550, 400, 700
Motherboard power connector: 24pin ATX
Cabling type: NonModular
Number of EPS connectors: 2
EPS power connector (4+4 pin): Yes
PCI Express connector: Yes
Number of SATA power connectors: 6
PCI Express power cable length: 62 cm
Peripheral (Molex) power cable length: 700, 550, 400
Other features
EPS cable length: 67 cm
Logistics data
Master (outer) cases per pallet: 120 pc(s)
Master (outer) case length: 570 mm
Master (outer) case height: 215 mm
Master (outer) case width: 275 mm
