Technical details
Sustainability certificates: ErP
Design
Fan location: Top
Product colour: Black
On/off switch: Yes
Cooling type: Active
Number of fans: 1 fan(s)
Fan diameter: 12 cm
Power
Combined power (12V): 3.6 W
Power protection features: Short circuit, Over voltage, Over total voltage, Over power, Under voltage, Over current
Combined power (+3.3V): 100 W
Max output current (+12V): 62.5 A
AC input voltage: 100 240 V
Input current: 10 5 A
Max output current (+5Vsb): 3 A
Power Factor Correction (PFC) type: Active
Hold time: 16 ms
Max output current (+3.3V): 20 A
Combined power (+5Vsb): 15 W
Max output current (12V): 0.3 A
Efficiency: 90%
Combined power (+5V): 100 W
Power Good signal delay range: 100 150 ms
AC input frequency: 50/60 Hz
Total power: 750 W
Combined power (+12V): 750 W
Max output current (+5V): 20 A
Operational conditions
Operating temperature (TT): 0 50 C
Weight & dimensions
Width: 150 mm
Height: 86 mm
Depth: 160 mm
Weight: 2.62 kg
Certification: TUV, CE, CCC, EAC, RCM, cTUVus, FCC, BSMI, BIS, UKCA
Performance
Mean time between failures (MTBF): 100000 h
Bearing technology: HDB
Power supply unit (PSU) form factor: ATX
ATX version: 3.1
80 PLUS certification: 80 PLUS Gold
Purpose: PC
Packaging data
Package height: 120 mm
Package weight: 2.9 kg
Package type: Box
Package depth: 310 mm
Package width: 194 mm
Ports & interfaces
Peripheral (Molex) power cable length: 740 mm, 620, 860 mm, 500 mm
SATA power cable length: 620, 740, 500 mm, 860
EPS power connector (4+4 pin): Yes
Peripheral (Molex) power connectors (4pin): 4
Number of SATA power connectors: 12
EPS power connector (8pin): Yes
Cabling type: FullyModular
ATX Power connector (24pin): Yes
Motherboard power cable length: 61 cm
Motherboard power connector: 24pin ATX
PCI Express power connectors (6+2 pin): 4
Safety warning
Warnings: Do not open the case risk of electric shock.
