Opis i karakteristike
Processor
Compatible processor series: Intel Core i5, Intel Core i7, Intel Core i9, Intel Pentium Gold, Intel Core i3, Intel Celeron
Processor manufacturer: Intel
Supported processor sockets: LGA 1700
Maximum number of SMP processors: 1
Processor socket: LGA 1700
Graphics
Parallel processing technology support: Not supported
Features
Motherboard form factor: mini ITX
Motherboard chipset: Intel B760
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Audio chip: SupremeFX S1220A
Motherboard chipset family: Intel
Audio output channels: 7.1 channels
Memory
Supported memory clock speeds: 6400 MHz, 6600, 6200, 5000, 7600, 5800, 5400, 7000, 4800, 6800, 5200, 6000, 5600, 7200 MHz
Maximum internal memory: 64 GB
Unbuffered memory: Yes
Memory channels: Dualchannel
Supported memory clock speed (max): 7600 MHz
Supported memory types: DDR5SDRAM
Number of memory slots: 2
Memory slots type: DIMM
Weight & dimensions
Width: 170 mm
Depth: 170 mm
Height: 50 mm
Network
Bluetooth: Yes
WiFi standards: 802.11g, WiFi 4 (802.11n), WiFi 6E (802.11ax), 802.11a, WiFi 6 (802.11ax), WiFi 5 (802.11ac), 802.11b
Top WiFi standard: WiFi 6E (802.11ax)
Ethernet interface type: 2.5 Gigabit Ethernet
Ethernet LAN: Yes
Bluetooth version: 5.3
WiFi: Yes
Internal I/O
ATX Power connector (24pin): Yes
Number of SATA III connectors: 4
USB 2.0 connectors: 1
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
Number of chassis fan connectors: 1
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
EPS power connector (8pin): Yes
CPU fan connector: Yes
Front panel audio connector: Yes
RGB LED pin header: Yes
12V power connector: Yes
BIOS
BIOS type: UEFI AMI
Packaging data
Package height: 185 mm
Package weight: 1.28 kg
Package depth: 94 mm
Package width: 226 mm
Packaging content
Cables included: SATA
User guide: Yes
Storage controllers
RAID levels: 5, 0, 1, 10
RAID support: Yes
Supported storage drive interfaces: M.2, SATA III
Number of storage drives supported: 6
Supported storage drive types: HDD & SSD
Number of HDDs supported: 4
Rear panel I/O ports
DisplayPorts quantity: 1
Ethernet LAN (RJ45) ports: 1
USB 2.0 ports quantity: 3
USB 3.2 Gen 1 (3.1 Gen 1) TypeA ports quantity: 3
HDMI ports quantity: 1
Microphone in: Yes
USB 3.2 Gen 1 (3.1 Gen 1) TypeC ports quantity: 1
Linein: Yes
Headphone outputs: 1
USB 3.2 Gen 2x2 TypeC ports quantity: 1
Expansion slots
Number of M.2 (M) slots: 2
PCI Express x16 (Gen 5.x) slots: 1
Other features
Weight: 644 g
