Opis i karakteristike
Design
Fan diameter: 12 cm
Cooling type: Active
Product colour: Black
Number of fans: 1 fan(s)
Power
AC input voltage: 220 240 V
Combined power (+5Vsb): 12.5 W
Max output current (+12V): 42 A
AC input frequency: 50 60 Hz
Combined power (+12V): 504 W
Max output current (+3.3V): 20 A
Combined power (+5V): 100 W
Combined power (+3.3V): 100 W
Total power: 550 W
Input current: 4 A
Combined power (12V): 3.6 W
Power Factor Correction (PFC) type: Active
Efficiency: 88%
Max output current (+5V): 20 A
Max output current (+5Vsb): 2.5 A
Power factor: 0.9
Max output current (12V): 0.3 A
Performance
Power supply unit (PSU) form factor: ATX
Purpose: PC
ATX version: 2.4
80 PLUS certification: 80 PLUS Bronze
Packaging data
Package type: Box
Package width: 230 mm
Package height: 95 mm
Package depth: 195 mm
Cables included: AC
Ports & interfaces
Motherboard power connector: 20+4 pin ATX
CPU power cable length: 55 cm
PCI Express connector: Yes
Number of SATA power connectors: 4
SATA power cable length: 550
PCI Express power connectors (6+2 pin): 1
ATX power connector (20+4 pin): Yes
Number of PATA power connectors: 2
CPU power connector (4+4 pin): Yes
Motherboard power cable length: 50 cm
PCI Express power cable length: 45 cm
Other features
Manual: Yes
Logistics data
Master (outer) case height: 215 mm
Master (outer) case length: 495 mm
Master (outer) case width: 250 mm
