Technical details
Sustainability certificates: ErP
Sustainability compliance: Yes
Design
Cooling type: Active
Fan diameter: 12 cm
Product colour: Black
Number of fans: 1 fan(s)
Power
Max output current (+3.3V): 20 A
Max output current (+5Vsb): 2.5 A
Power factor: 0.99
Input current: 10/5 A
Combined power (+5Vsb): 12.5 W
Max output current (+12V): 54 A
Combined power (+3.3V): 110 W
Power protection features: Under voltage, Over current, Short circuit, Over voltage, Over power, Overheating
AC input voltage: 100 240 V
AC input frequency: 50 60 Hz
Max output current (+5V): 20 A
Total power: 650 W
Power Factor Correction (PFC) type: Active
Combined power (12V): 3.6 W
Combined power (+5V): 110 W
Max output current (12V): 0.3 A
Combined power (+12V): 648 W
Weight & dimensions
Height: 86 mm
Width: 140 mm
Depth: 150 mm
Performance
80 PLUS certification: 80 PLUS Bronze
Mean time between failures (MTBF): 100000 h
Bearing technology: FDB
Purpose: PC
Power supply unit (PSU) form factor: ATX
ATX version: 2.4
Packaging content
Cables included: AC
Certification: CE / CB(62368+60950) / FCC(IC) / EAC / CCC / TUV / cTUVus / TUVS / RCM / NOM / BSMI / KC
Certificates
Compliance certificates: RoHS
Ports & interfaces
EPS power connector (4+4 pin): Yes
ATX Power connector (24pin): Yes
PCI Express power connectors (6+2 pin): 4
Peripheral (Molex) power connectors (4pin): 1
Number of SATA power connectors: 8
Motherboard power connector: 24pin ATX
Cabling type: NonModular
Logistics data
Harmonized System (HS) code: 84733020
Safety warning
Warnings: Do not open the case risk of electric shock.
