Opis i karakteristike
Design
Product colour: Black
Fan diameter: 14 cm
On/off switch: Yes
Cooling type: Active
Number of fans: 1 fan(s)
Fan speed: 0 2300 RPM
Fan location: Top
Power
AC input voltage: 100 240 V
AC input frequency: 47 63 Hz
Total power: 650 W
Input current: 10 A
Power protection features: Over current, Over voltage
Combined power (+5Vsb): 12.5 W
Max output current (+5Vsb): 2.5 A
Combined power (+5V): 110 W
Max output current (+12V): 54 A
Power Factor Correction (PFC) type: Active
Hold time: 12 ms
Combined power (12V): 3.6 W
Combined power (+3.3V): 110 W
Max output current (+3.3V): 20 A
Combined power (+12V): 648 W
Max output current (12V): 0.3 A
Max output current (+5V): 20 A
Operational conditions
Operating relative humidity (HH): 20 90%
Storage temperature (TT): 20 70 C
Operating temperature (TT): 0 40 C
Storage relative humidity (HH): 5 95%
Weight & dimensions
Height: 86 mm
Width: 150 mm
Depth: 160 mm
Certification: CE, FCC, TUV, cTUVus, EAC, BSMI, CTICK, CCC, Smark
Performance
80 PLUS certification: 80 PLUS Bronze
Mean time between failures (MTBF): 100000 h
Power supply unit (PSU) form factor: ATX
Purpose: PC
Packaging content
Cables included: AC, CPU, PCIe, Peripheral (Molex), SATA
Ports & interfaces
Cabling type: SemiModular
SATA power cable length: 500 mm, 150
CPU power cable length: 60 cm
Peripheral (Molex) power connectors (4pin): 1
Floppy disk drive cable length: 15 cm
Peripheral (Molex) power cable length: 150, 500 mm
Number of SATA power connectors: 3
PCI Express power cable length: 50 cm
Motherboard power connector: 20+4 pin ATX
PCI Express power connectors (6+2 pin): 2
Floppy drive power connector: 1
Motherboard power cable length: 60 cm
CPU power connector (4+4 pin): Yes
