Opis i karakteristike
Technical details
Status: Launched
Memory speed (max): 2400 MHz
Launch date: Q2'19
Product type: Processor
Supported memory types: DDR4SDRAM
Number of UPI links: 2
Servicing status: Baseline Servicing
Processor
Processor manufacturer: Intel
Processor socket: LGA 3647 (Socket P)
Processor ARK ID: 193390
Cooler included: No
Thermal Design Power (TDP): 85 W
Processor base frequency: 2.1 GHz
Processor generation: 2nd Generation Intel Xeon Scalable
Processor model: 4208
Processor boost frequency: 3.2 GHz
Processor cores: 8
Processor threads: 16
Processor codename: Cascade Lake
Processor operating modes: 64bit
Processor lithography: 14 nm
Package type: Box, Tray
Processor cache: 11 MB
Processor family: Intel Xeon Silver
Component for: Server/workstation
Graphics
Onboard graphics card: No
Discrete graphics card: No
Onboard graphics card model: Not available
Discrete graphics card model: Not available
Features
Scalability: 2S
Supported instruction sets: AVX, AVX512, SSE4.2, AVX 2.0
Market segment: Server
Execute Disable Bit: Yes
PCI Express CEM revision: 3.0
Export Control Classification Number (ECCN): 5A992C
Commodity Classification Automated Tracking System (CCATS): G077159
Embedded options available: No
PCI Express slots version: 3.0
Maximum number of PCI Express lanes: 48
Memory
Maximum internal memory supported by processor: 1.02 TB
ECC: Yes
Memory types supported by processor: DDR4SDRAM
Memory channels: Hexachannel
Memory clock speeds supported by processor: 2400 MHz
Operational conditions
Tcase: 78 C
Weight & dimensions
Processor package size: 76mm x 56.5mm
Packaging data
Package weight: 201 g
Package depth: 137 mm
Package height: 112 mm
Package width: 43 mm
Processor special features
Intel Resource Director Technology (Intel RDT): Yes
Intel Speed Shift Technology: Yes
Intel Optane DC Persistent Memory technology: No
Intel Speed Select technology Performance Profile (Intel SSTPP): No
Intel Optane DC Persistent Memory Supported: No
Intel Volume Management Device (VMD): Yes
AVX512 Fused MultiplyAdd (FMA) units: 1
Intel vPro Platform Eligibility: Yes
Intel TSXNI: Yes
Intel VTx with Extended Page Tables (EPT): Yes
Intel Turbo Boost Max Technology 3.0: No
Intel Deep Learning Boost (Intel DL Boost) on CPU: Yes
Intel 64: Yes
Intel Speed Select Technology (SST): No
Modebased Execute Control (MBE): Yes
Intel Speed Select Technology Base Frequency (Intel SSTBF): No
Intel Run Sure Technology: No
Intel Transactional Synchronization Extensions: Yes
Intel Hyper Threading Technology (Intel HT Technology): Yes
Intel Trusted Execution Technology: Yes
Intel Turbo Boost Technology: 2.0
Intel Virtualization Technology for Directed I/O (VTd): Yes
Intel Virtualization Technology (VTx): Yes
Enhanced Intel SpeedStep Technology: Yes
Intel AES New Instructions (Intel AESNI): Yes
Other features
Maximum internal memory: 1 TB
Logistics data
Harmonized System (HS) code: 85423119
Safety warning
Warnings: The product should be used in accordance with the manufacturer's instructions to avoid damage., Do not disassemble the processor or attempt to repair it yourself., Avoid direct contact with water and high humidity.
