Technical details
Supported memory types: DDR4SDRAM
Bus speed: 8 GT/s
Product type: Processor
Maximum memory: 128 GB
Status: Launched
Processor ID: 0x3E92
Maximum graphics card memory: 64 GB
Maximum resolution & refresh rate (DisplayPort): 4096 x 2304@60Hz
Launch date: Q2'19
Processor
Processor socket: LGA 1151 (Socket H4)
Configurable TDPdown frequency: 1.6 GHz
Cooler included: No
Processor base frequency: 2.2 GHz
Generation: 9th Generation
Processor ARK ID: 191052
Memory bandwidth supported by processor (max): 41.6 GB/s
Configurable TDPdown: 25 W
Processor manufacturer: Intel
Processor generation: 9th gen Intel Core i5
Thermal Design Power (TDP): 35 W
Processor cache type: Smart Cache
Processor operating modes: 64bit
Processor threads: 6
Processor boost frequency: 3.7 GHz
Processor cache: 9 MB
System bus rate: 8 GT/s
Processor series: 9th Generation Intel Core i5 Processors
Package type: Tray
Processor lithography: 14 nm
Processor model: i59500T
Component for: PC
Processor cores: 6
Processor codename: Coffee Lake
Processor family: Intel Core i5
Graphics
Onboard graphics card refresh rate at maximum resolution (eDP Integrated Flat Panel): 60 Hz
Onboard graphics card OpenGL version: 4.5
Onboard graphics card refresh rate at maximum resolution (DisplayPort): 60 Hz
Onboard graphics card maximum resolution (DisplayPort): 4096 x 2304 pixels
Onboard graphics card maximum resolution (HDMI): 4096 x 2304 pixels
Discrete graphics card: No
Onboard graphics card outputs supported: Embedded DisplayPort (eDP), DisplayPort, HDMI
Onboard graphics card maximum resolution (eDP Integrated Flat Panel): 4096 x 2304 pixels
Onboard graphics card dynamic frequency (max): 1100 MHz
Maximum onboard graphics card memory: 64 GB
Onboard graphics card 4K support: Yes
Onboard graphics card refresh rate at maximum resolution (HDMI): 24 Hz
Onboard graphics card: Yes
Onboard graphics card ID: 0x3E92
Number of displays supported (onboard graphics): 3
Onboard graphics card base frequency: 350 MHz
Onboard graphics card DirectX version: 12.0
Discrete graphics card model: Not available
Onboard graphics card model: Intel UHD Graphics 630
Features
Supported instruction sets: AVX 2.0, SSE4.1, SSE4.2
Intel Optane Memory module included: Yes
Commodity Classification Automated Tracking System (CCATS): G077159
Idle States: Yes
Scalability: 1S
Thermal solution specification: PCG 2015A
PCI Express CEM revision: 3.0
Execute Disable Bit: Yes
Export Control Classification Number (ECCN): 5A992C
Market segment: Desktop
Thermal Monitoring Technologies: Yes
PCI Express configurations: 2x8, 1x16, 1x8+2x4
CPU configuration (max): 1
PCI Express slots version: 3.0
Maximum number of PCI Express lanes: 16
Embedded options available: No
Memory
Maximum internal memory supported by processor: 128 GB
Memory types supported by processor: DDR4SDRAM
ECC: No
Memory channels: Dualchannel
Memory clock speeds supported by processor: 2666 MHz
Operational conditions
Tjunction: 100 C
Weight & dimensions
Processor package size: 37.5 x 37.5 mm
Processor special features
Intel vPro Platform Eligibility: Yes
Intel Stable Image Platform Program (SIPP): Yes
Intel Memory Protection Extensions (Intel MPX): Yes
Intel Software Guard Extensions (Intel SGX): Yes
Intel Transactional Synchronization Extensions: Yes
Intel 64: Yes
Intel Turbo Boost Technology 2.0 frequency: 3.7 GHz
Intel Secure Key: Yes
Intel Boot Guard: Yes
Intel OS Guard: Yes
Intel TSXNI: Yes
Intel Virtualization Technology for Directed I/O (VTd): Yes
Enhanced Intel SpeedStep Technology: Yes
Intel Trusted Execution Technology: Yes
Intel Quick Sync Video Technology: Yes
Intel Clear Video Technology: Yes
Intel VTx with Extended Page Tables (EPT): Yes
Intel Turbo Boost Technology: 2.0
Intel Identity Protection Technology (Intel IPT): Yes
Intel Virtualization Technology (VTx): Yes
Intel InTru 3D Technology: Yes
Intel Hyper Threading Technology (Intel HT Technology): No
Intel Clear Video HD Technology (Intel CVT HD): Yes
Intel AES New Instructions (Intel AESNI): Yes
Intel Optane Memory Ready: Yes
Other features
Maximum internal memory: 128 GB
Logistics data
Harmonized System (HS) code: 85423119
Safety warning
Warnings: Do not dispose of the processors in the normal rubbish bin they require special disposal due to their potential environmental impact., Be careful when handling the processor to avoid damaging the delicate pins., Ensure that the CPU is properly mounted in the CPU socket to avoid damage.
