Features
Number of output phases: 1
Efficiency: 89%
Emergency Power Off (EPO): Yes
Number of input phases: 1
Output voltage Total Harmonic Distortion (THD): 3%
Output operation voltage (min): 110 V
UPS topology: Doubleconversion (Online)
Output operation voltage (max): 240 V
Crest factor: 3:1
Autorestart: Yes
Output voltage regulation: 1%
Waveform: Sine
Output power factor: 0.9
Automatic Voltage Regulation (AVR): Yes
Input operation voltage (max): 300 V
Audible alarm modes: Alarm when on battery, Fault, Low battery alarm, Overload alarm
Maximum current: 10 A
Output frequency: 47/63 Hz
Power protection features: Overdischarge, Overcharge, Overload
Output power capacity: 2 kVA
Response time: 0 ms
Output power: 1800 W
Audible alarm(s): Yes
Noise level: 50 dB
Input frequency: 40/70 Hz
Design
Display type: LCD
Product colour: Black
Cooling type: Active
Rack capacity: 2U
Form factor: Rackmount/Tower
Operational conditions
Operating altitude: 0 1000 m
Operating temperature (TT): 0 40 C
Operating relative humidity (HH): 20 90%
Weight & dimensions
Height: 88 mm
Width: 438 mm
Weight: 19 kg
Depth: 410 mm
Certification: EN 620402: 2006+AC: 2006, EN 6100032: 2014 (EN 6100042: 2009, EN 6100043: 2006+A2: 2010, EN 6100044: 2012, EN 6100045:2006, EN 6100046: 2014, EN 6100048: 2010, EN 6100022:2002,EN 61000411:2004) CE
Certificates
Compliance certificates: RoHS
Ports & interfaces
Emergency Power Off (EPO) connector: Yes
Serial interface: Yes
USB port: Yes
AC outlets quantity: 4 AC outlet(s)
RS232 ports: 1
Battery
Cold start: Yes
Battery recharge time: 4 h
