Technical details
Warranty period: 10 year(s)
Sustainability certificates: Triman, ErP
Compliance certificates: CCC, WEEE, RCM, Federal Communications Commission (FCC), RoHS, CE, EAC
Design
Cooling type: Active
Fan diameter: 12 cm
On/off switch: Yes
Fan location: Top
Product colour: Black
Number of fans: 1 fan(s)
Power
Power protection features: Surge & inrush protection (SIP), Under voltage, No load operation, Over power, Overheating, Surge protection, Short circuit, Over voltage
Efficiency: 90%
Total power: 750 W
Combined power (+5Vsb): 15 W
Max output current (+5V): 20 A
Combined power (+3.3V): 110 W
Max output current (+12V): 62.5 A
AC input voltage: 100 240 V
Input current: 10 5 A
Combined power (12V): 3.6 W
Max output current (+3.3V): 20 A
Combined power (+12V): 750 W
Max output current (12V): 0.3 A
AC input frequency: 50/60 Hz
Max output current (+5Vsb): 3 A
Combined power (+5V): 110 W
Power Factor Correction (PFC) type: Active
Operational conditions
Operating temperature (TT): 0 40 C
Weight & dimensions
Height: 86 mm
Depth: 140 mm
Width: 150 mm
Performance
Bearing technology: FDB
Power supply unit (PSU) form factor: ATX
Mean time between failures (MTBF): 100000 h
80 PLUS certification: 80 PLUS Gold
Purpose: PC
ATX version: 3.1
Packaging data
Package type: Box
Packaging content
Cables included: AC
Cable tie(s) included: Yes
Ports & interfaces
SATA power cable length: 550, 650 mm, 750, 450
Cabling type: NonModular
Peripheral (Molex) power connectors (4pin): 2
PCI Express power connectors (6+2 pin): 3
CPU power cable length: 70 cm
Number of SATA power connectors: 8
CPU power connector (4+4 pin): Yes
Motherboard power connector: 20+4 pin ATX
PCI Express power connectors (16pin): 1
Peripheral (Molex) power cable length: 450 mm
Motherboard power cable length: 55 cm
ATX power connector (20+4 pin): Yes
Safety warning
Warnings: Do not open the case risk of electric shock.
