Dahua Technology WizMind IPC-HDBW5449RP-ASE-LED-0280B Bullet IP security camera Indoor & outdoor 2688 x 1520 pixels Ceiling cijene

Design
Product colour: White
Form factor: Bullet
Mounting type: Ceiling
IK code: IK10
Housing material: Metal
International Protection (IP) code: IP67

Power
Power source type: DC, PoE
DC output voltage: 12
Power consumption (max): 7.4 W
Power consumption (Power over Ethernet (PoE)): 3.3 W

Security
Intelligent Video Surveillance (IVS) system features: Heat map, Abandoned object, Missing object
Alarm output channels: 1
Video motion detection: Yes
Alarm input channels: 1
Mirror: Yes

Operational conditions
Storage temperature (TT): 40 60 C
Operating temperature (TT): 30 60 C
Operating relative humidity (HH): 0 95%

Management features
Web browser: Yes
Management software: Smart PSS;DSS;DMSS

Weight & dimensions
Weight: 716.4 g
Diameter: 12.6 cm
Height: 105 mm

Network
Ethernet LAN: Yes
Number of users: 20 user(s)

System requirements
Mobile operating systems supported: iOS, Android
Certification: CELVD: EN623681 CEEMC: Electromagnetic Compatibility Directive 2014/30/EU FCC: 47 CFR FCC Part 15, Subpart B UL/CUL: UL609501 CAN/CSA C22.2 No.609501

Performance
Connectivity technology: Wired
Placement supported: Indoor & outdoor
Type: IP security camera
Day/night mode: Yes
Dynamic range: 140 dB

Packaging data
Package weight: 929.7 g

Packaging content
Number of cameras: 1

Audio
Builtin microphone: Yes
Audio output channels: 1.0 channels
Audio formats supported: G.723, PCM, G.711
SignaltoNoise Ratio (SNR): 56 dB
Audio input channels: 1.0 channels

Storage
Compatible memory cards: SD
ROM capacity: 128 MB
Internal memory: 512 MB
Maximum memory card size: 256 GB

Ports & interfaces
Ethernet LAN (RJ45) ports: 1

Camera
Tilt angle range: 0 80
Minimum illumination: 0.0005 lx
Pan range: 0 355
Angle of rotation: 355
Lens viewing angle, horizontal: 115 48
Lens viewing angle, diagonal: 142 55
Lens viewing angle, vertical: 59 27
White balance: Natural, Auto, Manual, Street lamp, Outdoor
Camera shutter speed: 1/3 1/100000

Image sensor
Sensor type: CMOS
Progressive scan: Yes
Number of effective pixels (H x V): 2688 x 1520 pixels
Optical sensor size: 25.4 / 1.8 mm (1 / 1.8")

Video
Maximum resolution: 2688 x 1520 pixels
Supported graphics resolutions: 640 x 480 (VGA), 704 x 480, 2688 x 1520, 352 x 288, 352 x 240, 2304 x 1296, 2560 x 1440, 1920 x 1080 (HD 1080), 1280 x 720 (HD 720), 704 x 576, 1280 x 960
Noise reduction: Yes
Supported video modes: 1080p, 720p
Video compression formats: H.264B, H.264, H.264H, H.265
Frame rate: 60 fps
Privacy masking: Yes
Bit rate: H.264: 3 kbps20480 kbps H.265: 3 kbps20480 kbps
Gain control type: Auto/Manual
Total megapixels: 4 MP
Video formats supported: H.264+, H.265+
Noise reduction technology: 3D noise reduction
Region of Interest (ROI) encoding: Yes
Back Light Compensation (BLC): Yes
Bit rate control: Constant Bit Rate (CBR), Variable Bit Rate (VBR)
Highlight Compensation (HLC): Yes

Night vision
LED type: IR
Number of illumination LEDs: 3
Night vision: Yes
Night vision distance: 40 m

Lens system
Recognize distance (tele): 27.5 m
Focal length range: 2.7 12 mm
Identify distance (tele): 12.8 m
Detect distance (wide): 60.4 m
Observe distance (wide): 24.1 m
Observe distance (tele): 51.4 m
Identify distance (wide): 6 m
Focus: Motorized
Recognize distance (wide): 12 m
Maximum aperture number: 2.8
Number of lenses: 1
Closest focusing distance: 1.75 m
Detect distance (tele): 128.6 m
