Opis i karakteristike
Design
Product colour: Grey
LED indicators: Yes
Rack mounting: Yes
Power
AC input voltage: 100 240 V
Power consumption (max): 90.81 W
AC input frequency: 50 60 Hz
Power source: AC
Security
Access Control List (ACL) rules: 256
Security algorithms: SNMP, SSL/TLS, 802.1x RADIUS
IPMACPort binding: Yes
Access Control List (ACL): Yes
DHCP features: DHCP server, DHCP client
IGMP snooping: Yes
Operational conditions
Storage temperature (TT): 40 70 C
Operating temperature (TT): 0 50 C
Operating relative humidity (HH): 0 95%
Storage relative humidity (HH): 0 95%
Management features
Quality of Service (QoS) support: Yes
ARP inspection: Yes
Webbased management: Yes
Switch layer: L2
Switch type: Managed
System event log: Yes
Weight & dimensions
Weight: 3.15 kg
Height: 44 mm
Width: 440 mm
Depth: 250 mm
Network
Headofline (HOL) blocking: Yes
Networking standards: IEEE 802.3ab, IEEE 802.1w, IEEE 802.3az, IEEE 802.3an, IEEE 802.1D, IEEE 802.3z, IEEE 802.3ae, IEEE 802.3ad, IEEE 802.1s, IEEE 802.1x, IEEE 802.3p, IEEE 802.1Q, IEEE 802.3u
Cable types supported: Cat6a, Cat6, Cat7
Spanning tree protocol: Yes
10G support: Yes
Port mirroring: Yes
Broadcast storm control: Yes
Copper ethernet cabling technology: 10GBASET, 1000BASET, 100BASETX
Virtual LAN features: Portbased VLAN, MAC addressbased VLAN, Voice VLAN
VLAN support: Yes
Flow control support: Yes
Auto MDI/MDIX: Yes
Performance
Builtin processor: Yes
Protocols
Supported network protocols: IPv4, IPv6
Ports & interfaces
Power connector: ACin jack
Combo SFP ports quantity: 2
Basic switching RJ45 Ethernet ports quantity: 12
SFP+ module slots quantity: 2
Basic switching RJ45 Ethernet ports type: 10G Ethernet (100/1000/10000)
Data transmission
MAC address table: 16000 entries
Forwarding rate: 238.08 Mpps
Switching capacity: 320 Gbit/s
Jumbo frames support: Yes
Jumbo frames: 16000
Storeandforward: Yes
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
Multicast features
Multicast support: Yes
Optical fiber
Fiber ethernet cabling technology: 1000BASEX
