Opis i karakteristike
Design
LED indicators: Yes
Product colour: Black
Form factor: DIN rail
International Protection (IP) code: IP40
Stackable: Yes
Power
Power consumption (max): 7.44 W
DC input voltage: 12 48 V
Power source: DC
Input current: 1 A
Operational conditions
Storage relative humidity (HH): 5 95%
Operating temperature (TT): 20 65 C
Operating relative humidity (HH): 5 95%
Storage temperature (TT): 20 85 C
Management features
Switch type: Unmanaged
Quality of Service (QoS) support: Yes
Weight & dimensions
Depth: 28 mm
Height: 100 mm
Weight: 498 g
Width: 190 mm
Network
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3z
Auto MDI/MDIX: Yes
Copper ethernet cabling technology: 1000BASET
Performance
Mean time between failures (MTBF): 392267 h
Fanless: Yes
Ports & interfaces
SFP module slots quantity: 2
Basic switching RJ45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Basic switching RJ45 Ethernet ports quantity: 8
Logistics data
Harmonized System (HS) code: 85176990
Data transmission
MAC address table: 4000 entries
Jumbo frames support: Yes
Switching capacity: 20 Gbit/s
Transmission method: Storeandforward
Jumbo frames: 9000
Storeandforward: Yes
Forwarding rate: 14.88 Mpps
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
