Opis i karakteristike
Certification: UL (UL 60950), CSA (CSA 22.2), CE mark, FCC Part 15 (CFR 47) Class A, FCC Class B
Design
LED indicators: Yes
Product colour: Grey
Rack mounting: No
Power
DC input voltage: 12 V
Number of power supply units: 1
Redundant power supply (RPS) support: No
Power supply included: Yes
Security
Queue scheduling algorithms: Weighted Round Robin (WRR)
Operational conditions
Operating temperature (TT): 0 40 C
Storage relative humidity (HH): 5 90%
Storage temperature (TT): 20 70 C
Heat dissipation: 14.09 BTU/h
Operating relative humidity (HH): 10 90%
Management features
Switch type: Unmanaged
Quality of Service (QoS) support: Yes
Switch layer: L2
Weight & dimensions
Depth: 104 mm
Width: 160 mm
Weight: 430 g
Height: 30 mm
Network
Networking standards: IEEE 802.3x, IEEE 802.3az, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3u
Ethernet LAN data rates: 10,100,1000 Mbit/s
Auto MDI/MDIX: Yes
Full duplex: Yes
10G support: No
Flow control support: Yes
Copper ethernet cabling technology: 1000BASET, 100BASETX, 10BASET
Headofline (HOL) blocking: Yes
Half duplex: Yes
Performance
Mean time between failures (MTBF): 2066844 h
Packaging data
Quick start guide: Yes
Ports & interfaces
Gigabit Ethernet (copper) ports quantity: 8
Basic switching RJ45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Basic switching RJ45 Ethernet ports quantity: 8
Logistics data
Harmonized System (HS) code: 85176990
Data transmission
Switching capacity: 16 Gbit/s
MAC address table: 8192 entries
Jumbo frames support: Yes
Forwarding rate: 11.9 Mpps
Jumbo frames: 9216
Number of queues: 4
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
