Opis i karakteristike
Design
Cooling type: Active
Product colour: Black
Fan diameter: 13.5 cm
Illumination: No
Power
Max output current (+3.3V): 20 A
AC input voltage: 100 240 V
Total power: 750 W
AC input frequency: 50/60 Hz
Max output current (+12V1): 62.5 A
Max output current (+5V): 20 A
Combined power (+5V): 100 W
Max output current (12V): 0.3 A
Combined power (+3.3V): 100 W
Power Factor Correction (PFC) type: Active
Weight & dimensions
Weight: 1.96 kg
Depth: 150 mm
Height: 85 mm
Width: 150 mm
Performance
80 PLUS certification: 80 PLUS Gold
Purpose: PC
Bearing technology: FDB
ATX version: 3.1
Power supply unit (PSU) form factor: ATX
Packaging data
Package weight: 2.43 kg
Ports & interfaces
Number of SATA power connectors: 6
CPU power connector (4+4 pin): Yes
PCI Express power connectors (6+2 pin): 4
EPS power connector (8pin): Yes
Cabling type: FullyModular
ATX Power connector (24pin): Yes
Peripheral (Molex) power connectors (4pin): 3
CPU power cable length: 65 cm
Motherboard power cable length: 60 cm
SATA power cable length: 400
Motherboard power connector: 20+4 pin ATX
PCI Express power connectors (12+4 pin): 1
EPS power connector (4+4 pin): Yes
ATX power connector (20+4 pin): Yes
Peripheral (Molex) power cable length: 400
PCI Express power connectors (12+4 pin) cable length: 600 mm
