Technical details
Sustainability certificates: RoHS
Design
Cooling type: Active
Fan diameter: 12 cm
Fan location: Top
Product colour: Black
Number of fans: 1 fan(s)
Power
Power protection features: Under voltage, Over current, Short circuit, Over voltage, Overheating, Overload
Input current: 8 A
AC input voltage: 100 240 V
Combined power (+3.3V): 105 W
Max output current (+12V): 45.8 A
Combined power (12V): 3.6 W
Combined power (+5V): 105 W
Combined power (+12V): 550 W
Power Factor Correction (PFC) type: Active
Max output current (+5V): 20 A
AC input frequency: 50 60 Hz
Combined power (+5Vsb): 15 W
Total power: 550 W
Max output current (12V): 0.3 A
Max output current (+5Vsb): 3 A
Max output current (+3.3V): 20 A
Weight & dimensions
Height: 87 mm
Depth: 140 mm
Width: 150 mm
Weight: 2.02 kg
Performance
Power supply unit (PSU) form factor: PS/2
80 PLUS certification: 80 PLUS Gold
Purpose: PC
ATX version: 2.4
Packaging data
Package type: Box
Package weight: 2.33 kg
Ports & interfaces
Peripheral (Molex) power cable length: 150, 450
Floppy disk drive connector: Yes
Motherboard power cable length: 65 cm
Number of SATA power connectors: 6
Peripheral (Molex) power connectors (4pin): 3
PCI Express power connectors (6+2 pin): 2
SATA power cable length: 150, 450
Floppy drive power connector: 1
Motherboard power connector: 20+4 pin ATX
PCI Express power cable length: 50 cm
Cabling type: FullyModular
CPU power connector (4+4 pin): Yes
CPU power cable length: 65 cm
Logistics data
Harmonized System (HS) code: 84733020
