Opis i karakteristike
Design
Number of fans: 1 fan(s)
Product colour: Black
Fan diameter: 12 cm
Cooling type: Active
Power
AC input frequency: 47 63 Hz
Power protection features: Overload, Short circuit, Over voltage
Combined power (+5Vsb): 12.5 W
Power Factor Correction (PFC) type: Active
Total power: 500 W
Combined power (12V): 3.6 W
AC input voltage: 100 240 V
Max output current (+12V1): 41 A
Max output current (+3.3V): 18 A
Max output current (+5V): 18 A
Max output current (12V): 0.3 A
Max output current (+5Vsb): 2.5 A
Input current: 8 A
Weight & dimensions
Weight: 1.65 kg
Width: 140 mm
Height: 86 mm
Depth: 150 mm
Performance
ATX version: 2.3
Power supply unit (PSU) form factor: PS/2
Purpose: PC
80 PLUS certification: 80 PLUS Gold
Packaging data
Package weight: 2.06 kg
Ports & interfaces
Floppy drive power connector: 1
CPU power cable length: 65 cm
Cabling type: NonModular
SATA power cable length: 150, 500 mm
PCI Express power connectors (6+2 pin): 1
CPU power connector (4+4 pin): Yes
Peripheral (Molex) power connectors (4pin): 3
Number of SATA power connectors: 4
PCI Express power cable length: 50 cm
Floppy disk drive connector: Yes
Peripheral (Molex) power cable length: 150, 500 mm
Motherboard power connector: 24pin ATX
Logistics data
Harmonized System (HS) code: 84733020
