Opis i karakteristike
Processor
Supported processor sockets: LGA 1700
Processor manufacturer: Intel
Compatible processor series: Intel Core i7, Intel Core i9, Intel Pentium Gold, Intel Core i5, Intel Celeron, Intel Core i3
Processor socket: LGA 1700
Graphics
Parallel processing technology support: Not supported
Features
Motherboard form factor: ATX
Windows operating systems supported: Windows 11, Windows 10 x64
Audio chip: Realtek ALC4080
Audio output channels: 7.1 channels
Motherboard chipset family: Intel
Motherboard chipset: Intel B760
Component for: PC
Memory
Supported memory clock speeds: 5000, 5200, 4800, 6200, 7000, 5800, 5400, 7400, 6600, 6400, 5600, 7200, 6000, 6800, 7600, 7800
Maximum internal memory: 192 GB
Memory channels: Dualchannel
Unbuffered memory: Yes
ECC ompatibility: NonECC
Supported memory clock speed (max): 7800 MHz
Number of memory slots: 4
Memory slots type: DIMM
Supported memory types: DDR5SDRAM
Weight & dimensions
Depth: 244 mm
Width: 305 mm
Network
Bluetooth: Yes
Top WiFi standard: WiFi 6E (802.11ax)
Bluetooth version: 5.3
WiFi standards: 802.11b, 802.11g, WiFi 4 (802.11n), WiFi 5 (802.11ac), WiFi 6E (802.11ax), 802.11a, WiFi 6 (802.11ax)
Ethernet interface type: 2.5 Gigabit Ethernet
Ethernet LAN: Yes
WiFi: Yes
Internal I/O
Front panel audio connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
Number of chassis fan connectors: 4
USB 2.0 connectors: 1
Thunderbolt headers: 1
Number of SATA III connectors: 4
ATX Power connector (24pin): Yes
CPU fan connector: Yes
Peripheral (Molex) power connectors (4pin): 1
EPS power connector (8pin): Yes
S/PDIF out connector: Yes
12V power connector: Yes
RGB LED pin header: Yes
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
BIOS
BIOS type: UEFI AMI
BIOS memory size: 256 Mbit
Packaging content
Cables included: SATA
Storage controllers
RAID levels: 1, 5, 0, 10
RAID support: Yes
Supported storage drive interfaces: M.2, SATA III
Supported storage drive types: HDD & SSD
Number of storage drives supported: 7
Number of HDDs supported: 4
Rear panel I/O ports
Ethernet LAN (RJ45) ports: 1
USB 2.0 ports quantity: 4
USB 3.2 Gen 1 (3.1 Gen 1) TypeA ports quantity: 2
USB 3.2 Gen 2 (3.1 Gen 2) TypeA ports quantity: 1
DisplayPort version: 1.4
HDMI ports quantity: 1
DisplayPorts quantity: 1
HDMI version: 2.1
USB 3.2 Gen 2x2 TypeC ports quantity: 1
Headphone outputs: 1
USB 3.2 Gen 1 (3.1 Gen 1) TypeC ports quantity: 1
Microphone in: Yes
Linein: Yes
Expansion slots
PCI Express x1 (Gen 3.x) slots: 2
Number of M.2 (M) slots: 3
PCI Express x16 (Gen 3.x) slots: 1
